3D CAD DRAWING WORKSHOP

Course Information

3D Printing is an emerging technology in the 21st century and is rising in popularity because of the low costs needed to fabricate prototypes. As a result designers equipped with Computer Aid Design skills and 3D spatial awareness are increasing in demand. In this workshop, the participants will be taught basic 3D CAD Drawing skills using simple drag and drop methods to create a 3D product prototype.



Course Specifications

Key takeaways

Duration

Age group

Venue required

Indoor space for 3D CAD Drawing.

Teaching Language

Course Structure

  • Theory on 3D Printing Applications - 30 mins
  • 3D CAD Drawing (Indoors) - 30 mins
  • Creation of CAD object (Indoors) - 60 mins

2 hours

8 years old and above


English | Mandarin available

**No product will be created at the end**

  1. Mathematics Concepts like dimensions, proportion, measurements and shape geometry.
  2. Designing tools like Work planes, stacking, orthographic vs isometric drawing,
  3. Applications of 3D CAD drawing through drag and drop methods
MATHEMATICS


Participants will be taught to adjust object dimensions and read measurements. They will learn about geometry of shapes and stack shapes to draw the object.

STEM ELEMENTS

Using Tinkercad makes drawing 3D objects very easy. I got the hang of creating the objects after a while and could design my own drone out of it. Very good skill to learn.


Student, Yuan Ching Secondary School

ENGINEERING


Participants learn basic tools and functions of a CAD Drawing software. They will be taught isometric and orthographic views through drawing their very own object prototype.

STUDENT FEEDBACK
